ZHZF-300
Product Description: Our company specializes in the production of 3D car four-wheel positioning. The following products are just one of the software. The company has six softwares for the production, sales and operation of the company's four series of products. This software is available in multiple languages, but the first side is displayed in both Chinese and English. After selecting the language option, the language version is displayed. For details, please refer to the product manual, and the product guidance application. The relevant information will be attached when shipping. Software for export to countries.
Product Name: 22" large touch screen Zhuhai Zhanfeng (ZHZF) series 3D four wheel aligner
Product Name: 22" large touch screen Zhuhai Zhanfeng (ZHZF) series 3D four wheel aligner
Model: 3D ZHZF-300
3D car four wheel aligner: Genuine WIN8-32 bit operating system, Chinese and English multi-language optional operation surface. It is a simple and easy-to-understand software developed by our company.
Place of Origin: China - Zhuhai
Registered trademark: Fu Shida (ZHZF)
The software operation interface and software registration certificate are as follows:
.jpg)
The product appearance picture is as follows: (real, material, picture)
1.appearance, convenient operation, exclusive domestic production, the column with high strength Aluminum Alloy four mm thick square tube surface oxidation furniture mahogany color, beautiful and generous appearance, four fixture hanging on the side of the column two column. Easy to install at fixed height a certain height; the camera uses SONY imported camera 5 million pixel camera system, image processing speed of 30 frames per second, reflecting plate shell using aerospace Aluminum Alloy materials, dynamic visual algorithm technology, the software is easy to quickly read data; 3D dynamic image display operation guidance operation; rolling compensation, short wheelbase micro distance cart. Difference and track difference, accurate detection data, target real-time monitoring, standard four point fixture can check 10-23 inch rims, the equipment maintenance is simple, no need of regular Calibration; aluminum alloy steering wheel is convenient to check the direction parameters and the front wheel toe angle and other parameters; super database, free database updates once a year; products through the ISO quality system and the European Union CE security certification.2.The main technical parameters of the product are as follows:
| Location parameter | Accuracy (center value) | Accuracy range | Maximum measuring range |
| Display accuracy and measurement accuracy | ±0.01°/0.01mm | Measurement repeatability±0.01°or0.01mm | |
| Toe | ±0.015° | ±0.01° | ±30° |
| Dip angle | ±0.025° | ±0.01° | ±30° |
| Kingpin inclination | ±0.025° | ±0.01° | ±15° |
| Kingpin inclination | ±0.025° | ±0.01° | ±20° |
| thrust angle | ±0.015° | ±0.01° | ±6° |
| Maximum turning angle | ±0.015° | ±0.01° | ±30° |
| Recession angle | ±0.015° | ±0.01° | ±6° |
| Tread | ±0.25cm | ±0.01° | 3000mm |
| Wheelbase | ±0.25cm | ±0.01° | 8000mm |
| diagonal | ±2mm | ±0.3cm | 12000mm |
| Rolling radius | ±2mm | ±0.3cm | 700mm |
0.1. The camera has fast response, low temperature performance and good, can work at subzero temperature of about 30 degrees, the cart time is only 3S, the camera speed of 30 photos per second speed
0.2. Reflective board over the horizon, can be in the range of about 12 meters to find the target, you can do longer vehicle detection;
0.3. Measurement accuracy in the industry first-class;
0.4. Software supports a variety of reflective patterns;
0.5. The product has passed ISO quality system certification and export CE certification;
0.6. Guan Jian reflective panel, aluminum alloy mold design, to ensure product quality.
0.7. Computer attached to the 3D operation of the screen, simple and convenient operation. With its own installation and operation guide function
0.8. The software is easy to operate, easy to use, intuitive 3D display
0.9. National UNPROFOR, remote service system
10. All over the country are equipped with after-sales service outlets, remote technical support
11. Regular return visit system of products, continuous innovation, once a year free update data packets
12. The product is specially designed for the drainage design. It is convenient to check the data
13) free training staff
14. Dynamic calculation of the body parameters, not subject to the impact of the lifting machine
15. Automatic calculation of body parameters and rolling compensation body parameters
16. Software intuitive response to the four round of the condition and need to solve the problem of repair
